VACON® Fieldbus options

VACON® Fieldbus options are plug-in communication boards that let VACON® NX, VACON® 100 and VACON® 20 series drives integrate seamlessly into plant automation networks. The range covers AS-i, RS485-based Modbus RTU/Metasys N2, PROFIBUS DP, LonWorks, CANopen, DeviceNet, BACnet MS/TP, PROFINET, EtherNet/IP, Modbus TCP and EtherCAT, plus dual-port Ethernet variants with switch and redundancy support. Each option board is matched to specific drive slots and ordering codes, giving engineers a flexible way to standardize fieldbus communication across mixed installations. Key protocol boards carry PI and ODVA certification for guaranteed interoperability.

Specifications

AS-i Bus Option

OPTBK — Slots VACON® 100: CDE, VACON® 20X: E

Multiprotocol RS485 Option

OPTC2/OPTC8/OPTE2/OPTE8 — Modbus RTU, Metasys N2 protocol support

PROFIBUS DP Option

OPTC3/OPTC5/OPTE3/OPTE5 — PROFIBUS DP-V0/DP-V1 protocol support

LonWorks Option

OPTC4 — LonWorks protocol, 3-pin plug connector

CANopen Option

OPTC6/OPTE6 — CANopen protocol support, VACON® profile and CiA 402-like profile

DeviceNet Option

OPTC7/OPTE7 — DeviceNet protocol support, VACON® profile and CIP AC Drive-like profile

Modbus TCP Option

OPTCI — Modbus TCP protocol, 1x RJ45 connector

BACnet MS/TP Option

OPTCJ — BACnet MS/TP (RS485-based) protocol, 5-pin plug connector

PROFINET Option

OPTCP — PROFINET protocol, VACON® profile and PROFIdrive-like profile

EtherNet/IP Option

OPTCQ — EtherNet/IP protocol, VACON® profile and CIP AC Drive-like profile

Dual-Port Ethernet Option

OPTE9 — Modbus TCP/UDP, PROFINET, EtherNet/IP; 2x RJ45 with built-in switch

Advanced Dual-Port Ethernet Option

OPTEA — Features as OPTE9 plus PROFINET System Redundancy S2, ProfiSAFE over PROFINET

EtherCAT Option

OPTEC — EtherCAT protocol support, based on BECKHOFF ASIC, 2x RJ45 connectors

Certifications

OPTE3/OPTE5 certified by PI for PROFIBUS standard; OPTE9 certified by ODVA (EtherNet/IP) and PI (PROFINET Conformance Class B)
