VACON® Functional extensions

VACON® Functional Extension option boards add flexibility to VACON® AC drives by expanding digital and analog I/O, enabling Safe Torque Off safety functions, and providing dedicated interfaces for a wide range of encoder and resolver feedback devices. Each board slots directly into the drive to match application-specific requirements, from simple relay and thermistor inputs to advanced closed-loop motor control with EnDat, SSI, BiSS C or Sin/Cos encoders. This modular approach lets engineers tailor a VACON® drive precisely to their process without redesigning the base unit.

Specifications

Safe Torque Off (OPTBJ)

Up to SIL3 using two independent digital input channels

Safe Torque Off (OPTAF)

Up to SIL2, PL d, Cat. 3 using 2 independent digital input channels

Digital Inputs (OPTA1)

6 digital inputs, 24 V DC

Analog Inputs (OPTA1)

2 analog inputs (0...10 V or -10…+10 V or 0…20 mA)

Analog Output (OPTA1)

1 analog output (0…10 V or 0…20 mA)

Relay Outputs (OPTA2)

2 pcs NO/NC relay outputs

Relay & Thermistor (OPTA3)

1 NO/NC relay output, 1 NO relay output, 1 PTC thermistor input

Encoder Voltage Supply (OPTA4/OPTA5)

Selectable +5/+15/+24 V

Digital Inputs (OPTAL)

6 digital inputs, 42…240 V AC

PT100 Measurement Range (OPTB8)

-30…+200°C

PT100 Inputs (OPTB8)

2 PT100 sensor inputs (3-wire); channel 3 allows 1-3 sensors in series

Relay Outputs (OPTB5)

3 NO relay outputs

High-Voltage Digital Inputs (OPTB9)

5 digital inputs, 42…240 V AC

Resolver Excitation Frequency (OPTBC)

Configurable, 2-20 kHz

Encoder Voltage Supply (OPTBB/OPTBE)

Selectable +5/+12/+15 V

Analog I/O (OPTB4)

1 galvanically isolated analog input (0…20 mA), 2 galvanically isolated analog outputs (0…20 mA)
