OPTIMASS 3400
Compact Coriolis mass flowmeter engineered for precise low-flow and dosing measurement across liquids and gases.
The OPTIMASS 3400 delivers direct mass flow measurement using proven Coriolis technology, ideal for critical dosing, metering, and batching operations. Operating reliably from -40°C to +150°C at pressures up to 300 bar, it handles both liquids and gases with exceptional accuracy. Available in multiple connection types—flanged (EN/ASME/JIS), threaded, welded, and hygienic clamp configurations—plus extensive digital communication options (HART, Fieldbus, PROFINET, EtherNet/IP, Modbus) for seamless process integration.
Specifications
- Product type
- Flowmeter
- Product family name
- OPTIMASS
- Product positioning
- For low flow and dosing applications
- Measurement principle
- Coriolis
- Measured media
- Liquids, Gases
- Process pressure
- max. 300 barg/4351 psig
- Process temperature
- -40…+150°C/-40…+302°F
- Measuring tube
- Austenitic stainless steel (1.4404/316L), Austenitic alloy (2.4602/Alloy 22)
- Flange connections
- EN (1092-1): DN15 ASME (B 16.5): ½" JIS (B 2220): 15A
- Thread connections
- Female: ¼ NPT
- Other connections
- Welded end
- Hygienic connections
- Clamp (DIN 32676): DN10Tri-Clamp: ½
- Certificates/Approvals Ex
- ATEX, IECEx, NEPSI, EAC Ex, cFMus, INMETRO, KCs, UKEX
- Analogue outputs
- 4…20 mA
- Discrete outputs
- Limit switches, Pulse, Frequency, Status
- Digital outputs
- FOUNDATION™ Fieldbus, HART®, Profibus-PA, Profibus-DP, Modbus RTU, EtherNet/IP™, PROFINET, Bluetooth®, PROFINET (Ethernet-APL)
