2000

The Klay 2000 is an intelligent pressure transmitter engineered for demanding process applications in chemical, pulp, paper, and marine industries. It features a flush diaphragm design in AISI 316L stainless steel, delivers 0.1% accuracy across a 10:1 turndown ratio, and operates reliably from –20 °C to +80 °C. With integral push-button setup, ATEX/IECEx explosion certification, SIL2 functional safety, and optional HART protocol, this transmitter combines precision instrumentation with compliance for hazardous-area deployment across your operations.

Specifications

Measuring range min. max.

0,1…100 bar, optie 1000 bar

Process temperature

-20 °C…+80 °C

Accuracy

0,1 % of adjusted span

Process connections

1” BSP and pulp- and paper connections with flush diaphragm, all current threaded connections

Turn down

10:1

Output

4-20 mA 2-wire, option HART protocol

Adjustment

With 3 push buttons and display, without test pressure or with HART

Power supply

12 - 36 Vdc ( Ex: 12 - 26,5 Vdc)

Protection

IP66 (option IP68)

Ambient temperature

-20 °C...+70 °C

Diaphragm material

AISI 316L, option Hastelloy C or Gold plated

Wetted parts

AISI 316L

Electronics housing

AISI 304, option AISI 316

Certificates/approvals

Explosion safety : ATEX and IECEx Ex-nA, Ex-ia, Ex-ib and Ex-ec, EAC Ex-ia Marine approvals : Lloyd's, DNV, BV, CCS, ABS, Functional safety : SIL2
