TT-2000

The TT-2000 is a microprocessor-controlled temperature transmitter engineered for demanding industrial applications across Cyprus and the Middle East. It delivers 0.1% accuracy with Pt100 sensing elements and outputs 4-20 mA signals (with optional HART protocol) across wide supply voltages of 12-36 Vdc. The transmitter features stainless steel construction (AISI 316 wetted parts, AISI 304 housing with upgrade option), threaded and hygienic EHEDG/3A connections, plus flanged options, making it adaptable to diverse process environments. ATEX Ex-ia and IECEx Ex-ia certification ensures safe operation in explosive atmospheres, while IP66 protection (IP68 available) and intuitive push-button programming deliver reliability in harsh conditions.

Specifications

Measuring range

-50 °C…+200 °C

Accuracy

0,1 %

Insertion dimensions

Diameter 3….20 mm, length 5 mm…4 m

Process connections

Threaded, hygienic connections EHEDG and 3A, flanges

Pt100 element

3-wire, 1/3 DIN class B

Output

4-20 mA, 2-wire, Option HART protocol

Adjustment

With 3 push buttons and en display, without test temperature of with HART

Power supply

12 - 36 Vdc ( Ex: 12 - 26,5 Vdc)

Protection

IP66 (option IP68)

Ambient temperature

-20 °C...+70 °C

Wetted parts

AISI 316

Electronics housing

AISI 304, option AISI 316

Certificates/approvals

Explosion safety : ATEX Ex-ia and IECEx Ex-ia
